Where can I find a blow up of '63 T10?

[Norris W.]

Transmissions in boxes for several years and a poor memory aren't a good combo. I've got a couple of shims that I'm not exactly sure of.

[Phil P.]

motor manual has fair pictures *NM*

[Anthony F.]

Re: Where can I find a blow up of '63 T10?

Try this link and I think you will find what you need.

http://www.autogear.net/pdfs/T10%20booklet.pdf

[Anthony F.]

Re: Where can I find a blow up of '63 T10?

Sorry that the entire link did not high light.

http://www.autogear.net/pdf/t10%20booklet.pdf

or go to http://www.autogear.net and search for their T10 Transmission information.

[Norris W.]

Thanks, just what I needed. (NM) *NM*

[John D.]

Re: Where can I find a blow up of '63 T10?

Norris, What about the one in the 63 shop manual? See Fig 20. on page 7-16 for blow up. Same info appears in Clymers, etc. By the way sometimes shims are called spacers, etc.
Quite an extensive amount of info on your tranny in the manual. 1963 Corvette Shop Manual-readily available from NCRS. John

[Verne Frantz]

Re: Where can I find a blow up of '63 T10?
